The MSP430F5172IRSBR is an ultra-low-power, 16-bit mixed-signal microcontroller (MCU) in the MSP430F5xx family, available in a 40-pin WQFN package (5 x 5 mm) for applications such as the Internet of Things (IoT), industrial automation, sensor networks, medical devices and consumer electronics.

MSP430F5172IRSBR Product Features

Low-power modes: Multiple low-power modes are available, including LPM3 (standby mode, WDT mode, 1.1 µA at 3 V), LPM4 (shutdown mode, RAM hold, 0.9 µA at 3 V), and LPM4.5 (shutdown mode, 0.25 µA at 3 V). Wake-up time from standby mode is less than 5 µs.

High-performance processor: 16-bit RISC architecture with 40ns instruction cycle time and support for clock frequencies up to 25MHz.

Storage options: 32KB of internal Flash and 2KB of SRAM to meet the storage needs of most embedded applications.

Rich peripheral interfaces: including two 16-bit high-resolution timers (Timer TD0 and Timer TD1, both support high-resolution mode), a 16-bit timer TA0, 3-channel DMA, general-purpose serial communication interfaces (USCI_A0 supports enhanced UART, IrDA encoder and decoder, synchronous SPI; USCI_B0 supports I2C and synchronous SPI), and a 10-bit 200-bit serial interface. SPI; USCI_B0 supports I2C and synchronous SPI) and a 10-bit 200ksps analogue-to-digital converter (ADC) with a built-in reference voltage source and sample-and-hold functionality, supporting up to 8 external channels and 2 internal channels.

Flexible power management system: Integrated programmable voltage regulators support a wide supply voltage range of 1.8V to 3.6V with supply voltage supervision, monitoring and undervoltage reset.

Unified Clock System: Phase-locked loop (FLL) with frequency stabilisation control loop, low-power low-frequency internal clock source (VLO), low-frequency calibrated internal reference source (REFO), 32kHz crystal (XT1), and high-frequency crystals (XT1) supporting up to 25MHz.

Hardware Multiplier: Hardware multiplier supporting 32-bit operation to accelerate mathematical operations.

High-tolerance I/O: Provides up to 12 digital push-pull I/Os with 5V tolerance and maximum drive current of up to 20mA per pin.

MSP430F5172IRSBR Technical Specifications

 Core processor: MSP430 CPUXV2

Core specification: 16-bit

Speed: 25MHz

Connectivity: I2C, IrDA, SCI, SPI, UART/USART

Peripherals: undervoltage detection/reset, DMA, POR, PWM, WDT

Number of I/O: 31

Program memory capacity: 32KB (32K x 8)

Programme memory type: Flash

RAM Size: 2K x 8

Data Converter: A/D 11x10b

Oscillator type: Internal

Operating voltage: 1.8V to 3.6V

Operating temperature range: -40°C to +85°C

Package: 40-pin WQFN package (5mm x 5mm)

MSP430F5172IRSBR Applications

Analogue and digital sensor systems

LED Lighting

Digital power supplies

Motor Control

Remote control

Thermostats
