R5F524TAADFP is a 32-bit microcontroller (MCU) suitable for dual inverter control. R5F524TAADFP has a built-in floating point unit (FPU) that allows for easy programming of complex inverter control algorithms. This feature also supports users to drive two motors simultaneously. These features also greatly reduce the time required for software development and maintenance. The Renesas RX24T microcontroller operates within a wide voltage range of 2.7V to 5.5V and is suitable for inverter control.

R5F524TAADFP Basic Parameters

Product type: 32-bit microcontroller - MCU

Series: RX24T

Installation style: SMD/SMT

Packaging/Box: LFQFP-100

Core: RXv2

Program memory size: 8 kB

Data RAM size: 16 kB

Data bus width: 32 bits

ADC resolution: 12 bits

Maximum clock frequency: 80 MHz

Number of input/output terminals: 80 I/O

Power Supply Voltage - Minimum: 2.7 V

Power Supply Voltage - Maximum: 5.5 V

Minimum operating temperature: -40 ° C

Maximum operating temperature:+85 ° C

Analog power supply voltage: 5.5 V

DAC resolution: 8-bit

Data Ram type: SRAM

Data ROM size: 256 kB

Data Rom type: ROM

Height: 1.7 mm

Interface types: CAN, I2C, SCI, SPI, UART

Length: 14 mm

Humidity sensitivity: Yes

Number of ADC channels: 17 channels

Processor series: RX24T

R5F524TAADFP Application Areas

Motor Control: Customized specifically for motor control applications, capable of managing 2 motors, suitable for industrial automation and home appliances.

Industrial control: can be applied to various industrial control equipment to achieve precise control and data acquisition.

Consumer Electronics: Suitable for consumer electronics products that require high-performance processing and low power consumption.
