MSP430FR2632IYQWR is an ultra-low power MSP430 used for capacitive touch detection ™  Microcontroller, using CapTIvate ™  Touch technology, suitable for digital input Class D audio amplifiers in button, slider, scroll, and proximity sensing applications. The MSP430 MCU using CapTIvate technology provides the most integrated and autonomous capacitive touch solution on the market, with high reliability, noise resistance, and the lowest power consumption. TI's capacitive touch technology supports the use of both self capacitive and mutual capacitive electrodes in the same design scheme, maximizing flexibility. The MSP430 MCU using CapTIvate technology can penetrate thick glass, plastic casing, metal, and wood, and work in harsh environments including humid, greasy, and dirty environments.

MSP430FR2632IYQWR Features

Revolutionary FRAM Memory:

15.5KB FRAM (with a read and write lifespan of 10¹⁵times)

2KB SRAM, data maintains zero power consumption

100 times faster write speed than Flash

Professional touch engine:

Built in CapTIvate ™ Touch technology

Supports 16 self accommodating/mutual accommodating touch channels

Waterproof/glove touch recognition

Ultra low power consumption:

Activity mode: 100 μ A/MHz (typical value)

Standby mode (LPM3): 1.4 μ A (RTC running)

Wake up time:< 5μs

Rich peripheral resources:

16 bit ∑ - Δ ADC (12 channels)

4 16 bit timers

Hardware UART/I2C/SPI interface

Industrial grade reliability:

Working temperature:- 40°C ~ +85°C

ESD resistance: ± 8kV (HBM)

MSP430FR2632IYQWR Product Attributes

Product type: 16 bit microcontroller - MCU

Core:  MSP430

Program memory size:  8 kB

Data RAM size:  2 kB

Encapsulation/enclosure:  DSBGA-24

Maximum clock frequency:  16 MHz

ADC resolution:  10 bit

Number of input/output terminals:  17 I/O

Power Supply Voltage - Minimum:  1.8 V

Power Supply Voltage - Maximum:  3.6 V

Installation style:  SMD/SMT

Data bus width:  16 bit

Minimum operating temperature:  - 40 C

Maximum operating temperature:  + 85 C

Typical Applications

•Electronic smart locks, door keyboards, and readers

•Garage door system

•Invasion of HMI keyboard and control panel

•Electric blinds

• Remote control

• Personal electronic products

• Wireless speakers and headphones

• Handheld video game controller

•A/V receiver

•White goods

• Small appliances

•Horticulture and power tools
