The TMCS1123A1AQDVGRQ1 is an electrically isolated Hall effect current sensor with outstanding isolation performance and accuracy in the industry. This device also provides an output voltage proportional to the input current and features excellent linearity and low drift across all sensitivity options. The TMCS1123A1AQDVGRQ1 precision signal conditioning circuit with built-in drift compensation function can achieve a maximum sensitivity error of less than 1.4% within the temperature and life range without system-level calibration, or in the case of one-time room temperature calibration. Achieve a maximum sensitivity error of less than 0.9% (including lifetime and temperature drift).

Technical Specification

Current rated value: 80 A

Sensor type: Current Sense

Response time: 1 us

Accuracy: 0.1%

Frequency range: 250 kHz

Working power supply voltage: 5 V

Output type: Analog-Voltage

Height: 2.65mm

Length: 10.5mm

Maximum operating temperature: + 125 ° C

Minimum operating temperature: -40 ° C

Humidity sensitivity: Yes

Output voltage: 2.5V

Package/Box: SOIC-10

Application scenarios

TMCS1123A1AQDVGRQ1 is widely applied in the following scenarios, including:

Vehicle-mounted charger

• DC/DC converter

• Rotor excitation

• HVAC compressor

• High-voltage PDU

Electric vehicle charging
