ADF7020-1BCPZ: RF Transceiver - High Performance ISM Band FSK/ASK Transceiver IC

Basic Information:

Model No.: ADF7020-1BCPZ

Package: LFCSP-48

Type: RF Transceiver --FSK/ASK Transceiver ICs

Overview:

The ADF7020-1BCPZ is a low power, highly integrated FSK/ GFSK/ ASK/ OOK/ GOOK transceiver designed for use in the low UHF and VHF bands. The ADF7020-1BCPZ utilises an external VCO inductor that allows the user to set the operating frequency to any value between 135 MHz and 650 MHz. Using a 2-way frequency division circuit, users can operate the device at frequencies as low as 80 MHz, with a typical VCO range of approximately 10% of the operating frequency.The ADF7020-1BCPZ requires only a few external discrete components to build a complete transceiver, making it ideal for price and board area sensitive applications.

ADF7020-1BCPZ Specifications:

RF Family/Standard: VHF

Protocol: FM Radio

Modulation: ASK, FSK, GFSK, GOOK, OOK

Frequency: 80MHz ~ 650MHz

Data Rate (max): 200kbps

Power - Output: 13dBm (max)

Sensitivity: -119.2dBm

Serial Interface: SPI

Voltage - Supply: 2.3V ~ 3.6V

Current - Receive: 17.6mA ~ 20.1mA

Current - Transmit: 13mA ~ 21mA

Operating Temperature: -40°C ~ 85°C

Mounting Type: Surface Mount

Package/Case: 48-VFQFN Unpadded Pad, CSP

Vendor Device Package: 48-LFCSP-VQ (7x7)
