SPC584B70E1EH00X is a member of the family of devices superseding the SPC560Bx family. SPC584B70E1EH00X is built on the legacy of the SPC560Bx family, while introducing new features coupled with higher throughput to provide substantial reduction of cost per feature and significant power and performance improvement (MIPS per mW).

SPC584B70E1EH00X is 32-bit Power Architecture microcontroller for automotive ASIL-B applications.

Product Features

High performance e200z420

32-bit Power Architecture technology CPU

Core frequency as high as 120 MHz

Variable Length Encoding (VLE)

176 KB HSM dedicated flash memory (144 KB code + 32 KB data)

128 KB on-chip general-purpose SRAM (in addition to 64 KB core local data RAM

Multi-channel direct memory access controller (eDMA) with 64 channels

1 interrupt controller (INTC)

Comprehensive new generation ASIL-B safety concept

Enhanced low power support

Ultra low power STANDBY

Smart Wake-up Unit

Fast wake-up and execute from RAM

Up to 64 timed I/O channels with 16-bit counter resolution

1 Ethernet controller 10/100 Mbps, compliant IEEE 802.3-2008

8 MCAN interfaces with advanced shared memory scheme and ISO CAN-FD support

14 LINFlexD modules

7 Deserial Serial Peripheral Interface (DSPI) modules
