VND5N07TR is an N-channel power MOSFET belonging to the OMNIFET II™ and VIPower™ series, packaged in a DPAK (TO-252-3) package. This device is an intelligent power switch that integrates load drive, protection circuits, and a MOSFET, suitable for applications such as automotive electronics, industrial control, and power management.

Key Features (VND5N07TR)

Integrated protection functions

Current limit protection (fixed threshold)

Over-temperature protection (automatic shutdown)

Over-voltage protection (prevents damage from reverse voltage)

Low on-resistance (RDS(on)): 200mΩ (typical), reducing power consumption and improving efficiency

Load voltage (VLOAD): 55V (maximum)

No external power supply (Vcc/Vdd) required, simplifying design

High-speed switching performance: fast response, suitable for PWM control applications

Operating temperature: -40°C to +150°C (TJ)

Compliant with AEC-Q101 standards, suitable for automotive electronics

Compact package: DPAK (TO-252-3), suitable for high-density PCB layouts

Parameters: VND5N07TR

Load voltage (VLOAD): 55V

Continuous output current (IOUT): 3.5A

Peak output current (IPEAK): 5A

On-resistance (RDS(on)): 200mΩ

Input type: Non-inverting

Switching type: General-purpose

Package: DPAK (TO-252-3)
