The MSP430FR2512IPW16 is an ultra-low-power MSP430™ microcontroller (MCU) for capacitive touch sensing with CapTIvate™ touch technology for cost-sensitive applications where the application employs 1 to 16 capacitive pushbuttons or proximity sensing.The MSP430FR2512IPW16 MCU is suitable for applications Electromagnetic interference, oil, water and grease, creating value and high performance. These devices provide an IEC-certified solution that consumes up to five times less power than competitive solutions and supports proximity sensing and touch operation through glass, plastic, and metal coatings.

MSP430FR2512IPW16 Features

CapTIvate™ technology - capacitive touch

Performance

Two simultaneous fast electrode scans

Proximity sensing

Reliability

Improved immunity to powerline, RF and other environmental noise

Built-in extended spectrum, auto-tuning, noise filtering and dithering algorithms

Provides a reliable touch solution with 10V RMS common-mode noise, 4kV electrical fast transients, and 15kV electrostatic discharge in accordance with IEC-61000-4-6, IEC-61000-4-4, and IEC-61000-4-2 standards

Reduced RF emissions simplify electrical design

Supports metallic touch and waterproof designs

Flexibility

Up to 8 self-capacitive electrodes and 16 intercapacitive electrodes

Mix of self and mutual capacitive electrodes in the same design

Supports multi-touch functionality

Wide capacitance detection range; 0 to 300pF wide electrode range

Low power consumption

Wake-on-touch current less than 4µA for both sensors

Wake-on-Touch state machine supports electrode scanning while the CPU sleeps

Hardware acceleration for ambient compensation, filtering and threshold detection

MSP430FR2512IPW16 Product Attributes

Product Category: 16-bit Microcontrollers - MCUs

Core: MSP430

Programme memory size: 8 kB

Data RAM size: 2 kB

Package / Case: TSSOP-16

Maximum clock frequency: 16 MHz

ADC resolution: 10 bit

Number of inputs/outputs: 11 I/Os

Supply voltage - min: 2 V

Supply voltage - max: 3.6 V

Mounting style: SMD/SMT

Data bus width: 16 bit

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C
