The AD8657ARMZ are dual-channel, micropower, precision rail-to-rail input/output amplifiers optimised for low-power and wide operating supply voltage range applications.

The AD8657ARMZ is supplied from a 2.7 V to 18 V supply and has a typical quiescent supply current of 18 μA. These devices feature ADI's patented DigiTrim® tuning technology, which results in very low out-of-phase voltages, and the AD8657ARMZ also offers high immunity to electromagnetic interference.

With low supply current, low offset voltage, very low input bias current, wide supply voltage range, and rail-to-rail inputs and outputs, the AD8657ARMZ is ideal for current monitoring in process and motor control applications. In wireless/remote sensor/transmitters, the combination of precision features of these devices is well suited for DC gain and buffering processing of sensor front ends or high impedance input sources.

The AD8657ARMZ is rated over the extended industrial temperature range (-40°C to +125°C).

AD8657ARMZ - Applications

Portable Operating Systems

Current monitors

4 mA to 20 mA loop drivers

Buffering/level shifting

Multi-pole Filters

Remote/Wireless Sensors

Low Power Transconductance Amplifiers

AD8657ARMZ - Features

High voltage (18 V) micro-power consumption: 22 µA (max)

Low out-of-phase voltage: 350 µV (max)

Low input bias current: 20 pA (max)

Gain bandwidth product: 230 kHz (AV = 100, typical)

Unit gain crossover: 230 kHz

-3 dB closed-loop bandwidth: 305 kHz

Single supply: 2.7 V to 18 V

Dual-supply supply: ±1.35 V to ±9 V

Unit gain stabilisation

Excellent immunity to electromagnetic interference
