The HMC394LP4E is a low noise GaAs HBT programmable 5-bit counter in a 4x4 mm lead-free surface mount package. At input frequencies up to 2.2 GHz, the device can perform continuous frequency division in the N range 2 to 32. The output voltage swing is 800 mV, and the duty cycle is inversely proportional to N. At 100 kHz offset, the counter has additive SSB phase noise as low as −153 dBc/Hz, making it ideal for low-noise frequency synthesizer applications.

Basic parameter

Model: HMC394LP4E

Maximum operating frequency: 2.2GHz

Minimum operating frequency: 0 Hz

Scale: 2 to 32

Operating temperature: -55 °C to + 85°C

Installation style: SMD/SMT

Working power current: 194 mA

Working power supply voltage: 5 V

Output power: 4 dBm

Package/box: QFN-24

The HMC394LP4E is suitable for a wide range of applications, including but not limited to:

Satellite communication system

peer-to-peer

Point-to-multipoint radio

LMDS

SONET
