Commodity Model:R5F523E6MGFM

Trade Name:32-bit Microcontrollers - MCU

Brand:Renesas

Particular Year:25+

Package:LFQFP-64

Delivery Date:New and original

Stock: 2000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Renesas
Model
R5F523E6MGFM
Package
LFQFP-64
Describe
32-bit microcontroller - MCU RX23E-B 256K/32K QFP64

Product Description

The R5F523E6MGFM is a high-performance microcontroller designed by Renesas for industrial sensor equipment ‌. Key features include a built-in, high-precision 24-bit Delta-Sigma A/D converter with a maximum data rate of 125kSPS and RMS noise reduced to about one-third of the RX23E-A, suitable for high-speed and low-noise applications ‌.


Features

Analog Front End (AFE)

24-bit Delta-Sigma A/D converter with integrated programmable gain amplifier: up to 24-bit effective resolution, data rate 3.8SPS to 125 KSPS, 4nV/°C offset drift, 1ppm/°C gain drift

5V analog inputs: 8 sets of differential inputs, 16 single-ended inputs

±10V analog inputs: 2 sets of differential inputs, 4 single-ended inputs

16-bit/analog converter: DNL = ±1LSB, INL = ±5LSB

Reference voltage source: 10ppm/°C low temperature drift performance, with excellent temperature stability

Excitation current source: Matched programmable current source, ideal for measuring 3-wire resistance temperature detectors

MCU

CPU: 32-bit RXv2 core, operating frequency 32MHz, digital signal processing through DSP instructions and FPU

Communication interface: SPI x 1 channel, UART x 7 channel, I2C x 1 channel, CAN x 1 channel


Application field

The RX23E-B series is used in a wide range of industrial sensor devices, including:

Industrial automation ‌ : used in weight scales, strain gauges, pressure/flow control ‌.

Measuring instruments ‌ : data acquisition, laboratory instruments and other equipment requiring high precision measurement ‌.

High-end sensor system ‌ : suitable for high-end sensor equipment, measuring instruments and test equipment, especially force-sensitive sensors in industrial robots ‌.
