Service Telephone:86-755-83294757
Trade Name:Accelerometer
Brand:ADI
Particular Year:24+
Package:LGA-14
Delivery Date:New and Original
Stock: 50000pcs
The ADXL345BCCZ is a small, thin, low-power triaxial accelerometer that provides high-resolution (13-bit) measurements of acceleration up to ±16g. The digital output data is in 16-bit binary complement format and can be accessed via SPI (3-wire or 4-wire) or I2C digital interfaces.
The ADXL345BCCZ is well suited for mobile device applications. It can measure static gravitational acceleration in tilt detection applications, as well as dynamic acceleration due to motion or shock. Its high resolution (4 mg/LSB) enables measurement of tilt angle changes of less than 1.0°.
ADXL345BCCZ Applications
Mobile phones
Medical instruments
Gaming and spotting equipment
Industrial instrumentation
Personal navigation devices
Hard Disk Drive (HDD) Protection
ADXL345BCCZ Features
Low power consumption: as low as 23 μA in measurement mode and 0.1 μA in standby mode at VS = 2.5 V (typical)
Power consumption automatically scales with bandwidth
User-selectable resolution
10-bit fixed resolution
Full resolution with resolution increasing with g range, up to 13 bits at ±16 g (maintaining a scaling factor of 4 mg/LSB over all g ranges)
Embedded memory management system using FIFO technology to fully reduce host processor loads
Single/dual vibration detection
Activity/inactivity monitoring
Free fall detection
Supply voltage range: 2.0 V to 3.6 V
I/O voltage range: 1.7 V to VS
SPI (3-wire and 4-wire) and I2C digital interfaces
Flexible interrupt mode, mappable to any interrupt pin
Selectable measurement range via serial command
Selectable bandwidth via serial command
Wide temperature range (-40°C to +85°C)
Shock resistance: 10,000 g
Lead-free/RoHS compliant
Small and thin: 3 mm × 5 mm × 1 mm LGA package
Model
Brand
Package
Quantity
Describe
ADI
LGA-16
3000
Versatile 3-Axis, Digital Output, Ultra-Low Power Digital Accelerometer, LGA-16
ADI
LCC
15000
Single-axis ±70 g accelerometer with integrated dual-spectrum acceleration detection
ADI
LGA-14
3000
Low noise, low power consumption, wide bandwidth, 3-axis MEMS accelerometer
ADI
LGA-14
3000
Low noise, low power consumption, wide bandwidth, 3-axis MEMS accelerometer
ADI
LGA-14
3000
Low noise, low power consumption, wide bandwidth, 3-axis MEMS accelerometer
ADI
LGA-14
3000
Low noise, low power consumption, wide bandwidth, 3-axis MEMS accelerometer
ADI
CLCC-14
3000
Low noise, low drift, low power 3-axis MEMS accelerometer with digital output
