The LMG2100R026VBNR device is a 93V continuous, 100V pulse, 53A half-bridge power stage with integrated gate driver and enhanced gallium nitride (GaN) FETs. The device consists of two GaN FETs, driven by a high-frequency GaN FET driver in a half-bridge configuration.

Features:

Integrated half-bridge GaN FETs and drivers

93V continuous, 100V pulse rated voltage

The package is optimized for easy PCB layout

High transfer rate switch, low ringing

5V external bias power supply

3.3V and 5V input logic levels are supported

Gate drivers can achieve switching frequencies up to 10MHz

Excellent propagation delay (typical value 33ns) and matching (typical value 2ns)

Internal bootstrap supply voltage clamp to prevent GaN FET overdrive

Power rail undervoltage for locking protection

Low power consumption

Exposed top QFN package for top cooling

Large GND pad for bottom cooling

Applications:

• Buck, boost, buck - boost converter

• LLC Converter

• Solar inverter

• Telecommunications and server power

• Motor drive

• Power tools

• Class D audio amplifier
