The TAS5711PHPR is a 20W, highly efficient digital audio power amplifier for driving stereo bridged speakers. A serial data input allows processing of up to two discrete audio channels and seamless integration with most digital audio processors and MPEG decoders. The device accepts a wide range of input data and data rates. A fully programmable data path routes these channels to the internal speaker drivers.

Features

Audio input/output

20-W power input from 18-V supply to 8-load

Wide PVDD range from 8V to 26V

Efficient Class D operation eliminates the need for a heat sink

One serial audio input (two audio channels)

2.1 mode (2 SE + 1 BTL)

2.0 mode (2 BTL)

Single filtered PBTL mode supported

I2C address selection pins (chip select)

Supports 8-kHz to 48-kHz sample rates (LJ/RJ/I2S)

Audio/PWM processing

Independent channel volume control, 24 dB to mute

Independent dynamic range control for satellites and sub-channels

21 programmable Biquads for speaker equalisation and other audio processing functions

DRC filters with programmable coefficients

DC blocking filter

Support for 3D effects

Applications

TVs

iPod™ docks

Sound bars
