Service Telephone:86-755-83294757
Trade Name:TCAN1051VDRBTQ1
Data Manual:TCAN1051VDRBTQ1.pdf
Brand:TI
Particular Year:23+
Package:VSOP8
Delivery Date:New and Original
Stock: 2500pcs
The TCAN1051VDRBTQ1 CAN transceiver family is compliant with the ISO1189-2 (2016) high speed CAN (Controller Local Area Network) physical layer standard. All devices are designed for CAN FD networks with data rates up to 2Mbps (megabits per second). Devices with a "G" suffix are designed to achieve data rates up to 5Mbps and devices with a "V" suffix have an auxiliary power input to provide I/O levels for setting input pin thresholds and RXD output levels. The devices in this series have a silent mode, also commonly referred to as listen-only mode. In addition, all devices offer a variety of protection features to increase the durability of the device and the network.
Product features
- AEC Q100 standard: meets the requirements of automotive applications
- Temperature class 1: -40°C to 125°C, TA
- HBM classification level: ±16kV
- CDM classification level: ±1500V
- Compliant with ISO 11898-2:2016 and ISO 11898-5:2007 physical layer standards
- Available in functionally safe versions
- Documentation to assist in the design of functionally safe systems
- "Turbo" CAN.
- All devices support classic CAN and 2Mbps CAN FD (flexible data rate), while the "G" option supports 5Mbps
- Short symmetrical propagation delay times and fast cycle times for increased timing margins
- Faster data rates in loaded CAN networks
- EMC performance: SAE J2962-2 and IEC 62228-3 support (up to 500kbps) without common mode choke
- I/O voltage range supports 3.3V and 5V MCUs
- Ideal passive behaviour when not powered
- Bus and logic pins in high resistance state (no load)
- Power-up/power-down interference-free operation on bus and RXD outputs
- Protection features
- IEC ESD protection up to ±15kV
- Bus fault protection: ±58V (non-H models) and ±70V (H models)
- VCC and VIO (V models only) power terminals with undervoltage protection
- Driver apparent timeout (TXD DTO) - data rates down to 10kbps
- Thermal shutdown protection (TSD)
- Receiver common mode input voltage: ±30V
- Typical cycle delay: 110ns
- Junction temperature range of -55°C to 150°C
- Available in SOIC (8) package and leadless VSON (8) package (3.0mm x 3.0mm) with improved automatic optical inspection (AOI) capability
Applications
- Automotive and transport
- All devices support high load CAN networks
- Heavy machinery ISOBUS applications - ISO 11783
