The AM26LV32EIPWR device consists of four differential line receivers and features a three-state output. This device is designed to meet the requirements of TIA/EIA-422-B and ITU Recommendation V.11 drivers at a lower supply voltage. This device is optimised for balanced bus transmission at switching rates up to 32MHz. With its three-state output, the device can be directly connected to bus-organised systems. The AM26LV32E includes a fault protection circuit that prevents the device from being exposed to unknown voltage signals at the receiver outputs. In the event of an open-circuit fault, a high-level state is generated at the corresponding output. The device supports local power-down applications using the I off circuit. The I off circuit disables the outputs to prevent current flow back into the device during power-down, which could cause damage.

AM26LV32EIPWR Features

• Meets or exceeds the requirements of TIA/EIA-422-B and ITU Recommendation V.11 standards

• Operates on a single 3.3V power supply

• Switching frequency up to 32MHz

• ESD protection for RS422 bus pins (see ESD rating)

• Low power consumption: 27mW (typical)

• Open-circuit failure protection

• ±7V common-mode input voltage range with ±200mV sensitivity

• Accepts 5V logic inputs and 3.3V power supply (enable input)

• Input hysteresis: 35 mV (typical)

• Pin-compatible with AM26C32 and AM26LS32

• Ioff supports local power-down mode operation

AM26LV32EIPWR Specifications

Supply voltage:    3V to 3.6V

Operating temperature:    -40°C to +85°C

Package:    16-TSSOP (4.4 × 5.1 mm)

Number of receivers: 4 differential channels

Input hysteresis: 35 mV (typical)

Data rate: 32 Mbps (maximum)

ESD protection: ±15 kV (HBM/IEC 61000-4-2 air gap discharge)

Packaging:    Tape and reel (TR)

AM26LV32EIPWR Applications

• High-reliability automotive applications

• Configuration control and printing support

• ATMs and currency counters

• Smart grids

• AC and servo motor drives
