INFINEON Semper™ NOR Flash is a non-volatile storage solution that integrates security features for automotive and industrial systems. Applications include automotive dashboards, Advanced Assisted Driving Systems (ADAS) and network communications. The NOR flash memory is compliant with automotive functional safety standards, as well as ASIL-B and ASIL-D standards. The device is AEC-Q100 compliant and features an EnduraFlex™ architecture that enables more than one million programming/erase cycles or 25 years of data retention over a temperature range of -40°C to +125°C. In addition, the device features Quad SPI, HyperBus and Octal interfaces that are compliant with the JEDEC xSPI standard.

S25HS512TDPMHI010 Specifications

Memory type: Non-volatile

Memory Format: Flash

Technology: FLASH - NOR

Storage capacity: 512Mb

Memory Organisation: 64M x 8

Memory Interface: SPI - Quad I/O, QPI

Clock frequency: 133 MHz

Write Cycle Time - Word, Page: -

Voltage - Supply: 1.7V ~ 2V

Operating Temperature: -40°C ~ 85°C (TA)

Mounting Type: Surface Mount Type

Package / Case : 16-SOIC (0.295", 7.50 mm wide)

Supplier Device Package: 16-SOIC

Base Part Number: S25HS512

Features

EnduraFlex™ architecture: partitioned memory provides up to 25 years of data retention and over 1 million program/erase cycles

JEDEC xSPI compliant

Operating voltage: 1.8V to 3.0V

Functional safety

Compliant with ISO 26262 ASIL B requirements

Compliant with ISO 26262 ASIL-D requirements

Temperature range

Automotive class 3: -40°C to 85°C
