The AD5593RBCPZ-RL7 integrates eight I/O pins that can be individually configured for DAC output, ADC input, digital output, or digital input. The I/O pin is driven by a 12-bit DAC when configured for analog output. DAC output ranges from 0 V to VREF, or 0 V to 2 x VREF. When configured as an analog input, the I/O pin is connected to a 12-bit ADC via an analog multiplexer. ADC input ranges from 0 V to VREF, or 0 V to 2 x VREF. I/O pins can also be configured as Universal Digital Input or Output (GPIO) pins. Access the GPIO register via I2C write/read operations to set or read back the GPIO pin state.

The AD5593R device is ideal for control & monitoring, and general purpose analog & digital I/O applications.

Product specifications:

Type: ADC, DAC

Number of channels: 8

Resolution (bit) : 12 b

Sampling rate (per second) : -

Data interface: I²C

Supply voltage sources: analog and digital

Voltage-supply: 1.8V ~ 5.5V

Operating temperature: -40°C ~ 105°C

Mounting type: surface mount type

Package/case: 16-WFQFN, CSP

Supplier package: 16-LFCSP-WQ (3x3)

Basic product number: AD5593
