Trade Name:MAXM86161EFD+T
Data Manual:MAXM86161EFD+T.pdf
Brand:Maxim
Particular Year:23+
Package:14-LGA
Delivery Date:New original
Stock: 1000pcs
MAXM86161EFD+T is an ultra-low power, fully integrated, optical data acquisition system. On the transmitter side, the MAXM86161 has 3 programmable high current LED drivers. On the receiver side, the device contains an efficient PIN photodiode and an optical reading channel. The optical readout channel has a low noise signal conditioning analog front end (AFE) that includes a 19-bit ADC, an industry-leading ambient light offset (ALC) circuit, and fence detection and replacement algorithms. With its low power consumption, compact size, ease of use/flexibility, and industry-leading ambient light suppression capabilities, the MAXM86161 is ideal for a wide range of light detection applications, such as heart rate detection and blood oxygen.
Advantages and characteristics:
Complete single channel, optical data acquisition system
Built-in algorithms are further enhanced to suppress fast environmental transients
The structure is optimized for reflex heart rate and SpO2 monitoring
Low dark current noise: < 50pA RMS (sampling to sampling difference)
Lower effective dark current noise can be achieved through multiple sampling modes and on-chip averaging
High resolution, 19-bit charge integrating ADC
3 low noise, 8 bit LED current Dacs
Excellent dynamic range in white card loopback test: >89dB (sampling to sampling difference)
Excellent range and inhibition of ambient light
Ambient photodetector current > 100μA
Environmental suppression: > 70dB@120Hz
Make wearables work with ultra-low power consumption
Low power operation, typical consumption of optical reading channel <10 μA@25sps
Short exposure integration period: 14.8μs, 29.4μs, 58.7μs, 117.3μs
Low turn-off current: 1.6μA (typical)
Miniature, 2.9mm x 4.3mm x 1.4mm, 14-pin OLGA package
Operating temperature range from -40°C to +85°C
Application:
Optimized for in-ear applications
Miniature package for mobile applications
Optimized performance for detection:
Continuous monitoring of HRV
Optical heart rate
Oxygen saturation (SpO2)
Model
Brand
Package
Quantity
Describe
Maxim
22-LGA
1000
Integrated photoelectric volume pulse wave method and electrocardiogram biosensor module I²C output 22-LGA
Maxim
14-LGA
1000
Integrated optical sensor module 14-LGA supporting mobile health applications
