The CYT2B94BACQ0AZSGST Traveo™ T2G MCU is based on ARM® Cortex®-M0+/M4F 32-bit dual core and provides high performance, enhanced human interface, high security and advanced networking protocols. Tailored for a wide range of automotive applications such as electrification, body control modules, gateways and infotainment.

The TRAVEO™T2G series is an evolution of the successful TRAVEO™T1G series.

The series supports the latest in-car networks, optimizes memory usage for higher performance, and has built-in dedicated hardware encryption units for improved in-car data security.

Product specifications:

Core processors: ARM® Cortex®-M0+, ARM® Cortex®-M4F

Kernel specification: 32-bit dual-core

Speed: 100MHz, 160MHz

Connection capacity: CANbus, FIFO, I²C, IrDA, LINbus, SPI, UART/USART

Peripheral: Power failure detection/reset, encryption - AES, DMA, LVD, POR, PWM, SHA, TRNG, WDT

Number of I/ OS: 63

Program storage capacity: 2.0625MB (2.0625M x 8)

Program memory type: Flash

EEPROM Capacity: 128K x 8

RAM size: 256K x 8

Voltage-power supply (Vcc/Vdd) : 2.7V to 5.5V

Data converter: A/D 52x12b SAR

Oscillator type: external, internal

Operating temperature: -40°C ~ 105°C (TA)

Mounting type: surface mount type

Package/case: 80-LQFP

Supplier Device Package: 80-LQFP (12x12)
