The NXH010P120M3F1PTG is a power module that contains a 10 mohm / 1200 V SiC MOSFET half-bridge and an Alumina (AL2O3) DBC thermistor in an F1 package. The SiC MOSFET switch uses M3S technology and is driven by an 18V-20V gate.

NXH010P120M3F1PTG Specifications:

Configuration: Half-Bridge

Descent time: 15 ns

Height: 12.35 mm

Id- Continuous drain current: 105 A

Length: 63.3mm

Maximum operating temperature: + 150°C

Minimum operating temperature: -40 °C

Installation style: Chassis

Number of channels: 2 channels

Package/housing: PIM-18

Package: Tray

Pd-power dissipation: 272 W

Product: SiC MOSFET Modules

Product type: MOSFET Modules

Rds On- drain-source on-resistance: 14.5 mOhms

Rise time: 15 ns

Series: NXH010P120M3F1PTG

Factory packaging quantity: 28

Subcategory: Discrete and Power Modules

Technology: SiC

Transistor polarity: N-Channel

Type: Power Module

Typical shutdown delay: 98 ns

Typical connection delay: 23 ns

Vds- drain-source breakdown voltage: 1.2kV

Vgs - grid - source voltage: -10 V, + 22 V

Vgs TH-gate source threshold voltage: 4.4V

Width: 34.1mm
