1.AM62A32ASMSIAMBRQ1 Description:

The AM62Ax is an extension of the Sitara™ automotive-grade heterogeneous Arm® processor family with embedded deep learning (DL), video and vision processing acceleration, display interfaces, and a wide range of automotive peripherals and networking options. The AM62Ax is built for a range of cost-sensitive automotive applications, including driver and interior monitoring systems and next-generation electronic mirror systems, as well as a broad range of industrial applications in factory automation, building automation, robotics and other markets. Built for a wide range of industrial applications in factory automation, building automation, robotics and other markets, the AM62Ax is cost-optimised to deliver high-performance computing for traditional and deep learning algorithms at the industry's best power/performance ratio, with a high level of system integration to enable scalability and lower cost for advanced automotive platforms that support multiple sensor modes in a standalone electronic control unit (ECU).

The AM62Ax includes up to four Arm® Cortex®-A53 cores with a 64-bit architecture, a vision processing accelerator (VPAC) with an image signal processor (ISP) and multiple vision assist accelerators, multiple deep learning (DL) and video accelerators, a Cortex®-R5F MCU channel core, and a Cortex®-R5F device management core. R5F device management core.The Cortex-A53 provides the powerful computational components needed for Linux applications, as well as implementations of traditional algorithms based on vision computing, such as driver monitoring.TI's seventh-generation ISP builds on the excellent existing ISPs, with the flexibility to handle a broader suite of sensors including RGB-IR, support for higher bit depths, and analytics-oriented features. applications. Key cores include Texas Instruments' (TI) next-generation C7000™ DSP (C7x) with scalar and vector cores, as well as a dedicated MMA deep learning accelerator, which achieves up to 2TOPS of performance in the industry's ultra-low power range when running at typical automotive worst-case junction temperatures of 125°C. The AM62A32A32A is the first deep learning accelerator in the industry to be designed for the next generation of C7000™ DSPs.

2.AM62A32ASMSIAMBRQ1 product applications:

- Driver Monitoring System (DMS)/Occupant Monitoring System (OMS)

- Electronic Rearview Mirror/Camera Mirror Systems (CMS)

- Machine Vision Cameras

- Barcode scanners

- Front Camera Systems

- Stick up camera/visual doorbells

- Autonomous Mobile Robot (AMR)

3.AM62A32ASMSIAMBRQ1 Product Attributes:

Product Category: Microprocessors - MPUs

Cores: ARM Cortex A53, ARM Cortex R5F

Number of Cores: 3 Core

Data bus width: 64 bit

Maximum clock frequency: 800 MHz, 1.4 GHz

Package / Case: FCBGA-484

L1 cache instruction memory: 32 kB

L1 cache data memory: 32 kB

Operating supply voltage: 750 mV

Series: AM62A3-Q1

Mounting style: SMD/SMT

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

Data RAM size: 64 kB, 512 kB

Interface types: CAN, Ethernet, GPIO, I2C, SPI, UART, USB

L2 cache instruction/data memory: 512 kB

Memory type: LPDDR4

Number of timers/counters: 12 Timer

Processor family: AM62Ax
