The R7FA0E1053CFJ is an entry-level, simple MCU in the RA0 family, offering excellent cost effectiveness and ultra-low power consumption. It uses the Arm Cortex®-M23 core and has a wide supply voltage range of 1.6V to 5.5V, providing CPU performance up to 32MHz. The RA0 series is ideal for cost-sensitive applications such as low-power, low-cost consumer electronics, small appliance system control, industrial system control, and building automation.

Product attribute

Product Category: ARM Microcontroller - MCU

Series: RA0E1

Installation style: SMD/SMT

Package/housing: LQFP-32

Core: ARM Cortex M23

Program memory size: 32 kB

Data bus width: 32 bit

ADC resolution: 12 bit

Max clock frequency: 32 MHz

Number of input/output terminals: 26 I/ OS

Data RAM size: 12 kB

Supply voltage - Minimum: 1.6V

Power supply voltage - Max: 5.5V

Minimum operating temperature: -40 °C

Maximum operating temperature: + 105°C

Package: Tray

Analog supply voltage: 1.6V to 5.5V

Data Ram type: SRAM

Interface type: I2C, SPI, UART

Humidity sensitivity: Yes

Number of ADC channels: 10

Number of timers/counters: 8 x 16 bit, 1 x 32 bit
