The F6513SAVGI8 is an 8-channel transmit active beamforming RFIC designed for application in Ku-Band planar phased array antennas for communications or radar applications. The IC has a single common RF input port and eight output channels. The eight independently controlled output channels can drive eight single-polarized elements or four dual-polarized elements of an electronically scanned array (ESA). Each channel has 6-bits of digital phase control covering 360° and 25dB of gain control with a minimum step size of 0.2dB, enabling precise beam pattern and polarization control. Operating from a single supply of 2.1–2.5V, the RFIC has 23dB of nominal small signal gain with a typical P1dB of 12.5dBm per channel.

Features

 13.75 – 17.3GHz operation

 Supports 4 dual-pol elements or 8 single-pol

 360° phase control with 6-bit resolution

 25dB gain control with 0.2dB minimum step

 23dB small signal gain

 12.5dBm output P1dB

 2.3V nominal single supply input

 Standard 1.8V digital logic

 Temperature compensation

 Temperature sensor with digital readout

 Advanced digital modes with fast beam steering

 On-chip beam-state memory

 3.8 × 4.6 × 0.9 mm, 62-pin FC-BGA package

Typical Applications

 Phased array antennas

 Ku-band SATCOM terminals

 Common Data Link (CDL) terminals

 Ku-band radar

 Aerospace and maritime

 Instrumentation
