The R7FA2L1AB3CFN 32-bit microcontroller cluster features ultra-low power consumption with a power-efficient 48MHz Arm® Cortex®-M23 CPU, including enhanced peripherals.The RA2L1 MCUs operate with power consumption as low as 64uA/MHz in active mode and 250nA in software standby mode.The devices are highly integrated with a 48MHz Arm Cortex-M23 CPU, enhanced capacitive touch-sensing unit, 32-bit timer, 12-bit ADC and CAN for high integration.

Category: Embedded Microcontrollers

Series: RA2L1

Package: Tray

Part Status: On Sale

Core Processor: ARM® Cortex®-M23

Core specification: 32-bit single core

Speed: 48MHz

Connectivity: CANbus, I2C, SCI, SPI, Smart Card, UART/USART

Peripherals: AES, Capacitive Touch, DMA, LVD, POR, PWM, Temperature Sensor, TRNG, WDT

Number of I/O: 66

Program memory capacity: 256KB (256K x 8)

Programme memory type: Flash

EEPROM Size: 8K x 8

RAM Size: 32K x 8

Voltage - Supply (Vcc/Vdd): 1.6V ~ 5.5V

Data Converter: A/D 17x12b SAR; D/A 1x12b

Oscillator Type: Internal

Operating Temperature: -40°C ~ 105°C (TA)

Mounting Type: Surface Mount

Supplier Device Package: 80-LFQFP (12x12)

Package/Housing: 80-LQFP

Base Product Number: R7FA2L1

Applications

General Purpose

Household appliances (washer/dryers, dishwashers, refrigerators, cooking cookers, water heaters)

Industrial automation (digital pressure gauges, sensors, safety modules, motor actuators)

Building automation (HVAC, smoke detectors, thermostats, alarm systems, lighting)

Medical and healthcare (high-end portable devices, diagnostics, imaging)
