Commodity Model:CY8C4024LQE-S413

Trade Name:32-bit Microcontroller - MCU

Brand:Cypress

Particular Year:25+

Package:QFN-32

Delivery Date:New and Original

Stock: 2000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Cypress
Model
CY8C4024LQE-S413
Package
QFN-32
Describe
PSoC 4000S Series 32-bit ARM Cortex-M0+ Microcontrollers

Product Description

The CY8C4024LQE-S413 is a 32-bit ARM Cortex-M0+ microcontroller in the PSoC 4000S series. This chip integrates multiple peripheral interfaces and high-performance analogue modules, making it ideal for low-power, high-performance embedded applications.


Features — CY8C4024LQE-S413

High-performance processor: Based on the ARM Cortex-M0+ core, with a maximum clock speed of 24MHz.

Memory resources: 16KB flash memory and 2KB SRAM.

Rich peripheral interfaces: Supports GPIO, I2C, SPI, UART, and other interfaces.

High-precision analogue peripherals: Integrated 16-channel ADC, suitable for sensor interfaces and data acquisition.

Low-power design: Suitable for applications with high power consumption requirements, such as portable devices and IoT devices.

Package type: 24-pin QFN package, suitable for compact designs.

Operating temperature range: -40°C to +85°C.

Capacitive touch sensing: Integrated CapSense™ technology, supporting capacitive touch buttons, sliders, and proximity sensing.

Programmable analogue modules: Supports programmable general-purpose, continuous, and switch capacitance analogue modules.


Typical applications — CY8C4024LQE-S413

Smart home: Touch button control, LED dimming.

Industrial control: PLC, motor drive, HMI panel.

Consumer electronics: Remote control, wearable devices.

IoT devices: Low-power sensor nodes.
