Service Telephone:86-755-83294757
Trade Name:LMG3410R150RWHR
Data Manual:LMG3410R150RWHR.pdf
Brand:TI
Particular Year:21+
Package:VQFN32
Delivery Date:New and Original
Stock: 2000pcs
The LMG341xR150 GaN power stages feature integrated drivers and protection, allowing designers to achieve higher levels of power density and efficiency in power electronics systems. The inherent advantages of the LMG341x over silicon MOSFETs include ultra-low input and output capacitance values, zero reverse recovery that reduces switching losses by 80%, and low switch node ringing that reduces EMI. These advantages enable dense and efficient topologies such as totem-pole PFC.
The LMG341xR150 provides a smart alternative to traditional cascode GaN and standalone GaN FETs by integrating a unique set of features to simplify design, maximize reliability and optimize the performance of any power supply. Integrated gate driver supports 100V/ns switching (nearly zero Vds ringing), sub-100ns current limit protects itself against accidental shoot-through events, thermal shutdown prevents thermal runaway, and system interface signals provide self-monitoring .
characteristic
• TI GaN process passes accelerated testing for real-world hard-switching mission profile reliability
• Supports high-density power conversion designs
Superior system performance compared to cascode or standalone GaN FETs
Low-inductance 8mm x 8mm QFN package simplifies design and layout
Adjustable drive strength ensures switching performance and EMI control
Digital fault status output signal
Only +12V unregulated power supply required
• Integrated gate driver
Zero common source inductance
20ns propagation delay ensures MHz-level operation
Process-tuned gate bias voltage ensures reliability
User Adjustable Slew Rate from 25V/ns to 100V/ns
Cycle-by-cycle overcurrent protection
• Strong protection
No external protection components required
Overcurrent protection, response time less than 100ns
Slew rate immunity better than 150V/ns
Transient Overvoltage Immunity
Overheating protection
UVLO protection for all power rails
• Device Options:
LMG3410R150: Latching Overcurrent Protection
LMG3411R150: Cycle-by-cycle overcurrent protection
