ADM2867EBRNZ is 5.7kVrms signal and power isolated RS-485 transceivers. These devices are designed for balanced transmission lines and comply with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E). The devices pass radiated emissions testing to the EN 55032 Class B standard with margin on a 2-layer printed circuit board (PCB) using two small external 0402 ferrites on isolated power and ground pins.

Product Features

5.7kVrms isolated RS-485/RS-422 transceiver

Low radiated emissions, integrated, isolated dc-to-dc converter

ESD protection on RS-485 A, B, Y, and Z pins

≥±12 kV IEC61000-4-2 contact discharge

≥±15 kV IEC61000-4-2 air discharge

High speed 25 Mbps data rate

Low speed 500 kbps data rate for EMI control

PROFIBUS compliant for 5 V VISO

Wide operating temperature range: −40°C to +105°C

High common-mode transient immunity: 250 kV/µs

Short-circuit, open-circuit, and floating inputreceiverfail-safe

Supports 192 bus nodes (72 kΩ receiver input impedance)

Full hot swap support (glitch free power-up/power-down)

Applications

Heating, ventilation, and air conditioning (HVAC) networks

Industrial field buses

Building automation

Utility networks

Energy meters
