The ADS1284IRHFR is a high-performance, single-chip analogue-to-digital converter (ADC). The device includes a low-noise programmable gain amplifier (PGA), delta-sigma modulator, and digital filters. The ADC supports two modes of operation for an optimal balance between power consumption and resolution.

The ADS1284IRHFR is available in a compact 24-lead 5mm x 4mm VQFN package with a full operating temperature rating of -40°C to +85°C and a maximum operating temperature range of -50°C to +125°C. The ADS1284IRHFR is designed to be used in a wide variety of applications, including industrial and commercial applications.

Features

Selectable operating modes

Low-power mode:

12mW (PGA = 1, 2, 4 and 8)

127dB SNR (250 SPS, PGA = 1)

High resolution mode:

18mW (PGA = 1, 2, 4 and 8)

130dB SNR (250 SPS, PGA = 1)

THD: -122dB

CMRR: 110dB

Dual Channel Multiplexer

Intrinsic Stability Modulator

Fast response over-range detector

Flexible digital filters:

Sine + Finite Impulse Response (FIR) + Infinite Impulse Response (IIR) (optional)

Linear or minimum phase options

Programmable high-pass filters

Offset and gain calibration

SYNC Input

Analogue supply: 5V or ±2.5V

Digital supply: 1.8V to 3.3V

Applications

- Energy exploration

- Seismic monitoring

- High-precision instrumentation
