The AD9251BCPZ-80 is a single-chip, dual-channel, 14-bit, 80 MSPS analog-to-digital converter (ADC) powered by a 1.8V supply, featuring an integrated high-performance sample-and-hold circuit and an on-chip reference voltage source. The AD9251BCPZ-80 adopts a multi-level differential pipeline architecture and is equipped with built-in output error correction logic. It can provide 14-bit accuracy at a data rate of 80 MSPS and ensure no code loss throughout the entire operating temperature range.

Product advantages

The AD9251BCPZ-80 is powered by a single 1.8V analog power supply, while the digital output driver is powered by an independent power supply to accommodate 1.8V to 3.3V logic.

The patented sampling-hold circuit maintains excellent performance at a maximum input frequency of 200 MHz, and it is low-cost, low-power consumption and easy to use.

The standard serial port interface supports various product features and functions, such as: DATA output formatting, internal clock divider, power-saving mode, DCO/DATA timing and offset adjustment, and reference voltage source mode, etc.

The AD9251BCPZ-80 is packaged in a 64-pin LFCSP package, complies with RoHS standards, and has a rated temperature range of -40 °C to +85°C within the industrial temperature range.

Typical applications

Communication

Diversity radio system

Multi-mode digital receiver

GSM, EDGE, W-CDMA, LTE, CDMA2000, WiMAX, TD-SCDMA

I/Q demodulation system

Intelligent antenna system

Battery-powered instrument

Handheld oscilloscope

Portable medical imaging

Ultrasound

Radar /LIDAR
