32-Bit Single-Core ICs Chip STM32H743VGT6 Arm Cortex-M7 MCU Of Flash 1MB RAM

Product Description Of STM32H743VGT6

STM32H743VGT6 devices offer three ADCs, two DACs, two ultra-low power comparators, a low-power RTC, a high-resolution timer, 12 general-purpose 16-bit timers, two PWM timers for motor control, five low-power timers and a true random number generator (RNG).

Specification

Product Status:Active

Core Processor:ARM® Cortex®-M7

Core Size:32-Bit Single-Core

Speed:480MHz

Connectivity:CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG

Peripherals:Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT

Number of I/O:82

Program Memory Size:1MB (1M x 8)

Program Memory Type:FLASH

RAM Size:1M x 8

Voltage - Supply (Vcc/Vdd):1.71V ~ 3.6V

Data Converters:A/D 36x16b; D/A 2x12b

Oscillator Type:Internal

Operating Temperature:-40°C ~ 85°C (TA)

Features Of STM32H743VGT6

32-bit Arm® Cortex®-M7 core with doubleprecision FPU and L1 cache: 16 Kbytes of data and 16 Kbytes of instruction cache allowing one cache line to be filled in a single access from the

256-bit embedded Flash memory; frequency up to 480MHz, MPU, 856DMIPS/2.14 DMIPS/MHz (Dhrystone 2.1), and DSP instructions

Reset and power management

3 separate power domains which can be independently clock gated or switched off to maximize power efficiency:

D1: high-performance capabilities for high bandwidth peripherals

D2: communication peripherals and timers

D3: reset/clock control/power management
