The RTS5444E is an advanced Type-C controller designed for source port applications. It supports USB Type-C specification version 1.3 and integrates configuration channel (CC) logic, VCONN power switches, VBUS power switches, 5V to 3.3V LDO regulators, and internal oscillators into a single chip. The RTS5444E supports standard USB, 1.5A, and 3A Type-C current modes and can be selected via the RP_SEL0/1 pin.

Features

According to USB Type-C specification version 1.3, all Type-C channel configuration (CC) features are supported

Type-C receiver device connection/separation detection

Type-C plug direction detection

Type-C standard USB and 1.5A current mode advertising

Built-in VCONN switch with overcurrent protection to support power capacity up to 300mA

Integrated microprocessor

Supports crystal free applications

Integrated 5V to 3.3V LDO

Built-in VBUS power switch supports power capacity up to 5V/1.5A

Programmable current limiting function protects the power supply from overcurrent and short circuit conditions

Overtemperature protection

The VBUS automatically discharges when the power switch is off

Reverse blocking function when the VBUS power switch is turned off

Application

• Laptops, desktops
