The RV1S9262ACCSP-10YC is a photocoupler with switching capability up to 15 Mbps with source-low output logic, consisting of an AlGaAs LED on the input side and an integrated circuit with a photodiode on the output side. The RV1S9262ACCSP-10YC is specifically designed to achieve high common-mode transient immunity (CMTI), a wide operating supply voltage range, and high-temperature operation at TA = 125 °C for IPM drivers.

Features

Active low output

Small size and long creepage distance (8.2 mm LSSO5)

High speed switching (15 Mbps)

High common mode transient immunity (CMH, CML = ±100 kV/μs, min)

Pulse width distortion (|tPHL -tPLH| = 20 ns, max)

Wide operating supply voltage range (VCC = 4.5 ~ 30 V)

Operating ambient temperature (125°C max)

High isolation voltage (BV = 5000 Vr.m.s.)

Embossing Tape Product: RV1S9262ACCSP-100x#KC0: 3500 pcs/roll

Lead Free Products

Safety Standard

UL: UL1577, double protection

CSA: CAN/CSA-C22.2 No.62368-1, reinforced insulation

VDE: DIN EN 60747-5-5 (optional)

Applications

IPM drives

Universal inverters
