The ACPL-K75T-500E is a high-speed digital CMOS optocoupler package for emerging electric vehicle applications.The ACPL-K75T-500E is available in a stretched SO-8 package form factor and is designed to be compatible with standard surface mount processes.

ACPL-K75T-500E Core Features

High isolation voltage: 5000Vrms electrical isolation to enhance system safety.

High speed signal transmission: propagation delay up to 100ns, rise/fall time 10ns, suitable for fast digital signal isolation.

Push-pull/totem pole output: can directly drive CMOS/TTL logic levels without additional buffer circuits.

Wide operating voltage range: 3V~5.5V supply, compatible with 3.3V/5V systems.

High interference immunity:

Common mode transient immunity (CMTI) up to 25kV/µs for noisy environments.

Industrial temperature range: -40°C ~ +125°C for harsh environments.

ACPL-K75T-500E Typical Applications

CAN bus and SPI communication interface

High temperature digital/analogue signal isolation

Automotive IPM drivers for DC-DC converters and motor inverters

Power transistor isolation
