Commodity Model:ACPL-M49T-500E

Trade Name:Optocoupler

Brand:BROADCOM

Particular Year:23+

Package:SO-5

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
BROADCOM
Model
ACPL-M49T-500E
Package
SO-5
Describe
Automotive R2Coupler™ 20 kBd Digital Optocoupler, SO-5

Product Description

ACPL-M49T-500E: Wide Operating Temperature Automotive R2Coupler™ 20 kBd Digital Optocoupler Configurable as Low Power, Low Leakage Phototransistor


Model: ACPL-M49T-500E

Package: SO-5

Type: Digital Optocoupler


Overview:

The ACPL-M49T-500E is a single-channel, high-temperature, high CMR, 20-kBd digital optocoupler that can be configured as a low-power, low-leakage phototransistor specifically for automotive applications. Over the extended temperature range, the ACPL-M49T-500E improves common-mode transient immunity to a minimum of 15kV/µs at VCM = 1500V.


ACPL-M49T-500E Specifications:

Series: R²Coupler™

Number of Channels: 1

Voltage - Isolation: 4000Vrms

Current Transfer Ratio (min): 32% @ 10mA

Current Transfer Ratio (Max): 80% @ 10mA

Input Type: DC

Output Type: Transistor

Voltage - Output (Max): 20V

Current - Output/Channel: 8mA

Voltage - Forward (Vf) (typical): 1.5V

Current - DC Forward (If) (Max): 20 mA

Operating Temperature: -40°C ~ 125°C

Mounting Type: Surface Mount

Package/Shell: 6-SOIC (0.173’, 4.40mm Width), 5 Leads

Supplier Device Package: 5-SO


ACPL-M49T-500E Applications

Automotive low-speed digital signal isolation interface

Inverter fault feedback signal isolation

Switching power supply feedback circuits
