The THS3491YR Current Feedback Amplifier (CFA) provides enhanced performance for applications that require minimum distortion at high output power levels from DC to values greater than 100MHz with a 100Ω load. The current feedback design maintains nearly constant bandwidth and distortion over a wide gain range, even though it is rated at 5V/V gain.

A slew rate of 8000V/µs provides a 10V PP output with low distortion and 100MHz frequency for severe loads. 900MHz, small-signal bandwidth provides low overshoot of less than 1.5% with a 10V step and less than 1.3ns rise and fall times. A peak output current drive value of greater than 500mA enables fast signal drive of highly capacitive loads.

Features

- Bandwidth:

- 900MHz (VO = 2VPP, AV = 5V/V)

- 320MHz (VO = 10VPP, AV = 5V/V)

- Slew rate: 8000V/µs (VO = 20VPP)

- Input voltage noise: 1.7nV/√Hz

- Bipolar supply voltage range: ±7 V to ±16 V

- Single supply voltage range: 14 V to 32 V

- Output Swing: 28VPP (±16V supply, 100Ω load)

- Linear output current: ±420 mA (typical)

- 16.8 mA trimmed supply current (low temperature coefficient)

- HD2 and HD3: Less than -75dBc (50MHz, VO =10VPP, 100Ω load)

- Rise and fall time: 1.3ns (10V step)

- Overshoot: 1.5% (10V step, AV = 5V/V)

- Current Limit and Thermal Shutdown Protection

- Shutdown Characteristics

Applications

- High voltage arbitrary waveform generators

- Signal generator for LCD testers

- Output Drivers for LCR Meters

- Power FET drivers

- Drivers for high capacitive load piezoelectric elements

- VDSL Line Driver

- Pin-Compatible Upgrade of the THS3095 (DDA)
