The ADXL363BCCZ is an ultra-low-power, 3-sensor combo consisting of a 3-axis MEMS accelerometer, temperature sensor, and ADC inputs for simultaneous conversion of external signals, with the entire system consuming less than 2 µA at an output data rate of 100 Hz, and 270 nA in motion-triggered wake-up mode. utilising the Serial Port Interface (SPI) for communication. All 3 sensors always have a 12-bit output resolution. The accelerometers are available in ±2g, ±4g and ±8g measurement ranges, with a resolution of 1 mg/LSB in the ±2g range.

Product Properties

Type: Digital

Axis: X, Y, Z

Acceleration range: ±2g, 4g, 8g

Sensitivity (LSB/g): 1000 (±2g) ~ 250 (±8g)

Bandwidth: 3.25Hz ~ 200Hz

Output Type: SPI

Voltage - Supply: 1.6V ~ 3.5V

Features: Adjustable Bandwidth, Sleep Mode, Temperature Sensor

Operating Temperature: -40°C ~ 85°C (TA)

Mounting Type: Surface Mount

Package/Housing: 16-TFLGA

Supplier Device Package: 16-LGA (3x3.25)

Applications

● Home care devices

● Wireless sensors

● Motion-enabled metering devices
