The HMC1020LP4ETR Power Detector is designed for RF power measurement and control applications for frequencies up to 3.9 GHz. The detector provides an accurate RMS representation of any broadband, single-ended RF/IF input signal. The output is a temperature compensated, monotonic representation of real signal power, measured with an input sensing range of 72 dB.

The HMC1020LP4ETR is ideally suited to those wide bandwidth, wide dynamic range applications requiring repeatable measurement of real signal power, especially where RF/IF wave shape and/or crest factor change with time.

The integration bandwidth of the HMC1020LP4ETR is digitally programmable with the use of input pins SCI1-4 over a range of more than 3 decades. This allows the user to dynamically set the operation bandwidth and also permits the detection of different types of modulations on the same platform.

HMC1020LP4ETR features an internal op-amp at the output stage, which provides for slope / intercept adjustments and enables controller application.

Features Of HMC1020LP4ETR

• Broadband Single-Ended RF Input

• ±1 dB Detection Accuracy to 3.9 GHz

• Input Dynamic Range: -65 dBm to +7 dBm

• RF Signal Wave Shape & Crest Factor Independent

• Digitally Programmable Integration Bandwidth

• Excellent Temperature Stability

• Power-Down Mode

• 24 Lead 4x4mm SMT Package: 16mm²

Typical Applications

The HMC1020LP4ETR is ideal for:

• Log –> Root-Mean-Square (RMS) Conversion

• Tx/Rx Signal Strength Indication (TSSI/RSSI)

• RF Power Amplifier Efficiency Control

• Receiver Automatic Gain Control

• Transmitter Power Control
