The TMUX7219MDGKR is a complementary metal-oxide-semiconductor (CMOS) switch with latch-up suppression in a single 2:1 (SPDT) configuration. The device operates from a single supply (4.5 V to 44 V), dual supply (±4.5 V to ±22 V), or asymmetrical supply (e.g., VDD = 12 V, VSS = -5 V). The TMUX7219MDGKR supports bi-directional analogue and digital signals from the VSS to VDD range on the source (Sx) and drain (D) pins.

Features

- Dual supply voltage range: ±4.5V to ±22V

- Single-supply voltage range: 4.5V to 44V

-55°C to +125°C operating temperature

- Low on-resistance: 2.1Ω

- Low charge injection: -10pC

- High current support: 330mA (max)

- Latch-up suppression

- Compatible with 1.8V logic levels

- Logic pins have integrated pull-up and pull-down resistors

- Fail-safe logic

- Rail-to-rail operation

- Bidirectional signal path

- Break-before-close switch

Applications

- Avionics flight control units

- Aircraft cockpit displays

- Precision flight control for stand-alone avionics

- Interconnections and distribution boxes

- Aerospace and defence
