The ADXL312WACPZ is a small, thin, low-power 3-axis accelerometer digital output data format is 16-bit binary and can be accessed via a Serial Port Interface (SPI) (3-wire or 4-wire) or I2C digital interface. Ideal for car alarm or black box applications. It measures static gravitational acceleration in tilt-sensing applications, as well as dynamic acceleration resulting from gravitational acceleration. Its high resolution (2.9 mg/LSB) resolves tilt changes as small as 0.25°. The built-in FIFO facilitates oversampling techniques to increase resolution to as little as 0.05°.

Product Properties

Type: Digital

Axes: X, Y, Z

Acceleration range: ±1.5g, 3g, 6g, 12g

Sensitivity (LSB/g): 345 (±1.5g) ~ 43 (±12g)

Bandwidth: 3.125Hz ~ 1.6kHz

Output Type: I²C, SPI

Voltage - Supply: 2V ~ 3.6V

Characteristics: Sleep Mode

Operating Temperature: -40°C ~ 105°C (TA)

Mounting Type: Surface Mount

Package/Shell: 32-LFQFN Exposed Pad, CSP

Supplier Device Package: 32-LFCSP-LQ (5x5)

Applications

● Car alarms

● Hill Start Assist (HSA)

● Electronic parking brake

● Data logger (black box)
