1ED3431MU12M is Single-channel 5.7 kV (rms) isolated gate driver IC with adjustable DESAT and soft-off. It consists of galvanically isolated single channel gate driver ICs in a small PG-DSO-16 package with a large creepage and clearance of 8 mm. The gate driver ICs provide a typical peak output current of 3 A, 6 A, and 9 A.

Product Features

• 650 V, 1200 V, 1700 V, 2300 V IGBTs, SiC, and Si MOSFETs

• 40 V absolute maximum output supply voltage

• ±3 A, ±6 A, and ±9 A typical sinking and sourcing peak output current

• Separate source and sink outputs for hard switching and with active Miller clamp/clamp driver

• Adjustment pins for parameter configuration from input side

• Adjustable IGBT soft turn-off after desaturation detection with resistor at ADJA pin

• Operation at high ambient temperature up to 125 °C with over-temperature shut down at 160 °C (±10 °C)

• Tight IC-to-IC propagation delay matching (tPDD,max = 30 ns)

• Undervoltage lockout protection with hysteresis for input and output side with active shut-down

• High common-mode transient immunity CMTI = 200 kV/µs

• Small space-saving DSO-16 fine-pitch package with large creepage distance (>8 mm)

Potential applications

• Industrial motor drives - compact, standard, premium, servo drives

• Solar inverters

• UPS systems

• Welding

• Commercial and agricultural vehicles (CAV)

• Commercial air-conditioning (CAC)

• High-voltage isolated DC-DC converters

• Isolated switch mode power supplies (SMPS)
