Trade Name:1ED3830MC12MXUMA1
Data Manual:1ED3830MC12MXUMA1.pdf
Brand:INFINEON
Particular Year:23+
Package:16-BSSOP
Delivery Date:New and Original
Stock: 1000pcs
The 1ED3830MC12MXUMA1 is part of the EiceDRIVER™ Enhanced 1ED38xx Series (X3 Digital Series) - a single-channel isolated gate driver with adjustable control and protection features including DESAT, Soft Shutdown, UVLO, Miller Clamp, Two-Level Turn Off (TLTO), and Faults to simplify the design of high-reliability systems. All parameter adjustments are accomplished from the inputs via the I2C interface (pins SDA and SCL).1ED3830MC12MXUMA1 is suitable for IGBT, SiC, and Si MOSFETs.
Product Attributes
Technology: Magnetic coupling
Number of Channels: 1
Voltage - Isolation: 5700Vrms
Common mode transient immunity (min): 200V/ns
Propagation Delay tpLH / tpHL (max): 270ns, 262ns
Rise/Fall Time (typical): 15ns, 15ns
Current - Output High, Low: 3A, 3A
Current - Peak Output: 3A
Voltage - Output Supply: 13V ~ 25V
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package/Housing : 16-BSSOP (0.295", 7.50mm wide)
Supplier Device Package: PG-DSO-16-28
Certification Body: UL, VDE
Potential Applications
Industrial Motor Drives - Compact, Standard, Advanced, Servo Drives
Solar Inverters
UPS systems
Welding
Commercial and Agricultural Vehicles (CAV)
Commercial Air Conditioning (CAC)
High Voltage Isolated DC-DC Converters
Isolated Switching Power Supplies (SMPS)
