Service Telephone:86-755-83294757
Trade Name:ICE3BR0665JZ
Data Manual:ICE3BR0665JZ.pdf
Brand:INFINEON
Particular Year:23+
Package:DIP7
Delivery Date:New and Original
Stock: 4000pcs
ICE3BR0665JZ is derived from ICE3BR0665J in DIP-7 package. The CoolSET® -F3R jitter series (ICE3BRxx65J) is the latest version of CoolSET® -F3. It targets for the OffLine battery adapters and low cost SMPS for lower power range such as application for DVD R/W, DVD Combi, Blue ray DVD player, set top box, etc. Besides inherited the outstanding performance of the CoolSET® -F3 in the BiCMOS technology, active burst mode, auto-restart protection, propagation delay compensation, etc., CoolSET® -F3R series has some new features such as built-in soft start time, built-in blanking window, built-in frequency jitter, soft gate driving, etc. In case a longer blanking time is needed for high load application, a simple addition of capacitor to BA pin can serve the purpose. Furthermore, an external auto-restart enable feature can provide extra protection when there is a need of immediate stop of power switching.
Features
• 650V avalanche rugged CoolMOS® with built-in Startup Cell
• Active Burst Mode for lowest Standby Power
• Fast load jump response in Active Burst Mode
• 65kHz internally fixed switching frequency
• Auto Restart Protection Mode for Overload, Open Loop, VCC Undervoltage, Overtemperature & Overvoltage
• Built-in Soft Start
• Built-in blanking window with extendable blanking time for short duration high current
• External auto-restart enable pin
• Max Duty Cycle 75%
• Overall tolerance of Current Limiting < ±5%
• Internal PWM Leading Edge Blanking
• BiCMOS technology provide wide VCC range
• Built-in Frequency jitter and soft driving for low EMI
