The TIOL1123LYAHR transceiver uses the IO-Link interface to implement industrial bi-directional point-to-point communications. When connected to an IO-Link master via a three-wire interface, the master initiates communication and exchanges data with the remote node, while the TIOL112(x) serves as a complete physical layer for communication. These devices are capable of withstanding IEC 61000-4-5 surges up to 1.2kV (500Ω) and have integrated reverse polarity protection. They can be easily connected to controller circuits via a simple pin-programmable interface.

Product Properties

Type: Transceiver

Protocol: I/O Link

Number of Drivers/Receivers: 1/1

Duplex: Half

Receiver hysteresis: 750 mV

Data Rate: 250kbps

Voltage - Supply: 7V ~ 36V

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Housing: 12-BGA

Vendor Device Package: 12-DSBGA (2.45x1.7)

Applications

● Field transmitters and actuators

● Factory automation

● Process automation

● IO-link PHYs in remote IOs
