The DS90UB940NTNKDRQ1 is an FPD-Link III deserialiser that, when used in conjunction with the DS90UB949/947/929-Q1 Serialisers, converts single- or dual-channel FPD-Link III streams to MIPI® CSI-2 format. The deserialiser is capable of operating over cost-effective 50Ω single-ended coaxial or 100Ω differential shielded twisted pair (STP) cable. The device is capable of recovering data from a single- or dual-channel FPD-Link III serial stream, and then converting the data to the Camera Serial Interface (CSI-2) format, which supports up to WUXGA and 1080p60 video resolutions (24-bit colour depth).

Device Specifications

Function: Deserialiser

Data Rate: 3.36Gbps

Input Type: FPD Link III, LVDS

Output Type: CSI-2, MIPI

Number of Inputs: 2

Number of Outputs: 5

Voltage - Supply: 1.14V ~ 1.26V, 3V ~ 3.6V

Operating Temperature: -40°C ~ 105°C (TA)

Mounting Type: Surface Mount

Package/Shell: 64-WFQFN Exposed Pad

Supplier Device Package: 64-WQFN (9x9)

Base Product Number: DS90UB940

Applications

• Automotive infotainment systems and instrument clusters:

- Automotive centre console displays

- Rear seat entertainment systems

- Automotive instrument cluster displays

- Automotive smart displays
