BGT24AR4E6433XUMA1 is a silicon-germanium MMIC that supports four independent chains of homodyne receivers. Each receiver consists of a downconverter operating in the 24 GHz ISM band. LO buffer amplifier is included to reduce LO drive requirements. If signal filtering and amplification are provided on chip.

Feature description:

• Gilbert-based four-channel homodyne 24 GHz downconverter with integrated IF filter and programmable gain baseband amplifier

• Single-ended RF terminals

• Low single sideband noise factor: NFSSB=10 dB (typical value)

• High frequency converter P1dB input compression point: -6 dBm (typical value)

• Low LO input power required: -6 dBm

• On-chip low level and temperature sensors

• Multiplex output of analog sensor signals

• Integrated saturation detector for downconverter and IF amplifier

• Disable downconverter and baseband amplifier modes via SPI

•IF chain testability

• Single supply voltage: 3.3V (typical)

• Low power consumption: 610 MW (typical)

200 GHz bipolar SiGe: C technology B7HF200

• Full ESD protection device

•VQFN-32-9 pin-free plastic package, including lead end inspection (LTI)
