The TDA5252 is a low-power single-chip FSK/ASK transceiver operating in the 915MHz frequency band, suitable for half-duplex low data rate communications. The chip features high integration, requiring only a minimal number of external components. It includes an efficient power amplifier, a low-noise amplifier (LNA) with automatic gain control (AGC), a dual-balanced mixer, a complex direct-conversion baseband filter, an analogue-to-digital converter (ADC), a digital signal processor (DSP), and a microcontroller unit (MCU).

TDA5252 Features

Wireless Communication Performance

Operating frequency: 915MHz (ISM band)

Modulation methods: Supports ASK (amplitude shift keying) and FSK (frequency shift keying) modulation

Data rate: Up to 64kbps, suitable for low-power wireless data transmission

Output power: 9dBm (approximately 8mW), providing stable wireless signal transmission

Receiver sensitivity: -109dBm, enhancing long-range communication capabilities

Low-Power Design

Operating Voltage: 2.1V to 5.5V, suitable for battery-powered devices

Receive Current: 9.1mA (typical)

Transmit Current: 12.5mA (typical)

Interface and Packaging

Data Interface: PCB surface mount, simplifying circuit design

Antenna Connection: Supports PCB antenna or external antenna

Environmental Adaptability

Operating temperature: -40°C to +85°C, suitable for industrial and outdoor environments

Technical specifications of  TDA5252

Operating frequency: 915MHz

Maximum data rate: 64kbps

Modulation method: ASK, FSK

Output power: 9dBm

Sensitivity: -109dBm

Operating voltage: 2.1V to 5.5V

Transmit current: 12.5 mA

Receive current: 9.1 mA

Package: TSSOP-38

Applications of  TDA5252

Remote keyless entry (RKE) systems

Industrial wireless sensor networks

Smart home remote control devices

Low-power Internet of Things (IoT) nodes
