The LM62440ALPQRJRRQ1 is a high performance DC-DC synchronous step-down device, high performance DC-DC synchronous step-down converter focused on automotive applications. The LM62440ALPQRJRRQ1 is an automotive-focused, high-performance DC-DC synchronous step-down converter with integrated high-side and low-side output currents of up to 4 A. It delivers up to 4 A of output current over a wide 3.0 V to 36 V input range. Tolerance support lasts up to 400 ms. The LM62440-Q1 implements power-down soft recovery to eliminate overshoot. The LM62440ALPQRJRRQ1 is specifically designed to minimise electromagnetic interference. The device integrates a pseudo-random spread spectrum adjustable SW node rise time, a low EMIVQFN-HR package featuring low switch node ringing, and an optimised pin layout for ease of use. The switching frequency can be synchronised between 200 kHz and 2.2 MHz to avoid noise-sensitive frequency bands. A 2.1-MHz or 400-kHz frequency factory option is also available to increase efficiency at low operating frequencies. A 2.1-MHz or 400-kHz frequency factory option is also available to increase efficiency at low operating frequencies or to reduce the size of the solution at high operating frequencies.

Product Attributes

Function: Buck

Output Configuration: Positive

Topology: Buck

Output Type: Adjustable

Number of Outputs: 1

Voltage - Input (Min): 3V

Voltage - Input (Max): 36V

Voltage - Output (Min/Fixed): 1V

Voltage - Output (Max): 34.2V

Current - Output: 4A

Frequency - Switch: 400kHz

Synchronous Rectifier: Yes

Operating Temperature: -40°C ~ 150°C (TJ)

Mounting Type: Surface Mount, Wettable Sides

Package/Housing: 14-VFQFN

Supplier Device Package: 14-VQFN-HR (4x3.5)

Applications

● Automotive infotainment systems and clusters

● Automotive ADAS and body electronics
