The TLE8366EV33 is a PWM step-down DC/DC converter with a built-in 1.8 A power switch, packaged in a small PG-DSO-8 with exposed pads. Three versions are available, two fixed voltage versions at 5.0 V, 3.3 V, and a variable voltage version called the TLE8366EV33 with a reference feedback voltage of only 600 mV. A wide input voltage range of 4.75 to 45 V makes the TLE8366EV33 suitable for a variety of applications. The device is designed for use in harsh automotive environments. The switching frequency, rated at 370 kHz, allows the use of small, economical inductors and capacitors, resulting in low and predictable output ripple and minimal board space. (The TLE8366EV33 has safety features such as cycle-by-cycle current limiting, thermal shutdown, and input undervoltage lockout. The TLE8366EV33 has safety features such as cycle-by-cycle current limit, thermal shutdown, and input undervoltage lockout. The enable function consumes less than 2 µA in shutdown mode, making power management for battery-powered systems easy.

Product Attributes

Function: Buck

Output Configuration: Positive

Topology: Buck

Output Type: Fixed

Number of Outputs: 1

Voltage - Input (Min): 4.75V

Voltage - Input (Max): 45V

Voltage - Output (Min/Fixed): 3.3V

Voltage - Output (Maximum): - Voltage - Output (Maximum): - Voltage - Output (Maximum): - Voltage

Current - Output: 1.8A

Frequency - Switch: 370kHz

Synchronous Rectifier: None

Operating Temperature: -40°C ~ 150°C (TJ)

Mounting Type: Surface Mount

Package/Shell: 8-SOIC (0.154", 3.90mm Width)

Supplier Device Package: PG-DSO-8

Applications

● HVAC

● Body control modules

● Instrument panels

● Linear regulators

● DC/DC converters

● IVN Transceivers
