The A1C15S12M3 is a converter-inverter brake (CIB) topology in an ACEPACK™ 1 package that integrates ST's advanced trench gate field-stop technology. This new IGBT technology is the best compromise between conduction and switching losses, maximising the efficiency of any converter system up to 20 kHz.A1C15S12M3 with DBC Cu Al2O3 Cu, converter-inverter brake topology, 1600 V, very-low-dropout rectifier for converters, 1200 V, 15 A IGBTs and diode, soft fast recovery diode, integrated NTC.

Product Properties

IGBT type: Trench field cut-off

Configuration: Three-phase inverter with brake

Voltage - Collector Breakdown (max): 1200 V

Current - Collector (Ic) (max): 15 A

Power - Max: 142.8 W

Vce(on) at varying Vge, Ic (max): 2.45V @ 15V, 15A

Current - Collector Cutoff (Max): 100 µA

Input capacitance (Cies) at varying Vce: 985 pF @ 25 V

Input: 3-phase bridge rectifier

NTC thermistor: Yes

Operating Temperature: -40°C ~ 150°C (TJ)

Mounting Type: Chassis Mount

Package/Housing: Module

Supplier Device Package: ACEPACK™ 1

Applications

• Inverters

• Motor Drives
